A2Z EV proudly introduces the market's premier aftermarket NACS to CCS1 adapter, specifically designed for North American electric vehicles. With our adapter, your vehicle is now compatible with any NACS DC fast charging station.

Dedicated to precision, our design prioritizes the seamless integration with your vehicle, ensuring utmost safety and compatibility.

For added safety, the A2Z Typhoon Plug incorporates two temperature sensor switches. The first sensor derates the charging process upon reaching a certain temperature, while the second sensor halts charging, the temperature are strategically placed within the adapter. Charging can resume once the temperature normalizes and the adapter is reconnected. It's worth noting that during real-life testing, thermal shutdown was never reached.

Specifications:

• Rated Amperage : 500A.
• Rated Voltage : 100~1000VDC.
• Conductor Material : Silver plated copper.
• Contact resistance : 5m ohms.
• Shell Material : UL-94-V0 PA66.
• Operating Temperature : -30°C to 50°C.
• Security : Dual temperature sensor switch.
• Sealing gasket : Silicon rubber.
• Locking : Dual locking mechanism in one.
• Security : Locks into the vehicle while charging (if the vehicle incorporates a charge port locking pin).
• Degree of protection : IP54 (mating) & IP67 (enclosing).

Product certifications:

• Will be UL2252 tested and certified once released by UL.
• CE certification (in the process).
• FCC certification (obtained).
